Prefabricated modular house
A modular house with a separate bedroom and striking floor-to-ceiling panoramic windows. The bright open-plan living area combines comfort and contemporary design — ideal for a stylish holiday retreat or year-round living.
Size: 30m²
Sleeping places: 4-6
Size: 30m²
Sleeping places: 4-6
Are you interested in this model and would like to receive an offer with further information?
Similar model
Virtual 3D tour
Step inside and take a virtual walk through every corner of the house, as if you were physically there.
Floor plan
A barn-style home offers a separate bedroom and a spacious living area with kitchen and dining zone. Panoramic windows flood the interior with natural light, creating an airy and modern atmosphere — perfect for couples or small families.
External dimensions: 6m x 5m x 3.45m
Size: 30m²
Sleeping places: 4
External dimensions: 6m x 5m x 3.45m
Size: 30m²
Sleeping places: 4
Are you interested in this model and would like to receive an offer with further information?
Information and Equipment
FRAME CONSTRUCTION
ROOF
- Standing Seam
- OSB 3 Board (22 mm)
- Counter batten (45*45 mm)
- Wind insulation membrane
- Wooden frame (195*45 mm, C24)
- Mineral wool insulation (200 mm)
- Vapor barrier
- Counter batten (25*45 mm)
- Interior finishing
WALLS
- Exterior finishing
- Sheathing (20*95 mm)
- Counter batten (45*45 mm)
- Wind insulation membrane
- Wooden frame (145*45 mm, C24)
- Mineral wool insulation (150 mm)
- Vapor barrier
- Counter batten (25*45 mm)
- Interior finishing
FLOOR
- Floor covering
- OSB 3 Board (18 mm)
- Vapor barrier
- Wooden frame (195*45 mm, C24)
- Mineral wool insulation (200 mm)
- Fiber Cement Board (10 mm)
- Furring strip (45*145 mm)
- Furring strip (20*95 mm)
INNER WALLS
- Interior finishing
- OSB 3 Board (12 mm)
- Wooden frame (95/145*45 mm, C24)
- Mineral wool insulation (100/150 mm)
- Wind insulation membrane
- Counter batten (20*45 mm)
- Interior finishing
INTERFLOOR (LOFT)
- Floor covering
- OSB 3 Board (12 mm)
- Pine cladding (19 mm)
- Wooden frame (95*45 mm, C24)
EXTERIOR FINISHING
Roof covering - Standing seam (0.5mm, with high zinc content, matt surface).
The main facade offers several options such as:
The facade incorporates various materials, including decorative metal panels for the top and bottom elements.
Thermo pine boards is utilised for elements surrounding door and windows.
You have the flexibility to select the material and color for the facade.
The main facade offers several options such as:
- Scandinavian pine cladding (120x19 or 146x19, vertical or horizontal) - painted with two layers of acrylic paint
- Standing seam (0.5mm, with high zinc content, matt surface)
- Thermo pine boards (120x20) - painted with two layers of acrylic impregnation
The facade incorporates various materials, including decorative metal panels for the top and bottom elements.
Thermo pine boards is utilised for elements surrounding door and windows.
You have the flexibility to select the material and color for the facade.
WINDOWS AND ENTRANCE DOOR
Windows material is PVC with energy-saving glass.
Can be double glazed (basic) or triple glazed (optionally).
Color options:
Wooden or aluminum windows are available to choose from.
Can be double glazed (basic) or triple glazed (optionally).
Color options:
- White inside - colored (Ral9005) outside (basic)
- Colored (Ral9005) inside - colored (Ral9005) outside (optionally)
- Individual color
Wooden or aluminum windows are available to choose from.
INTERIOR FINISHING
Options for the interior finishing:
Walls and ceiling
Flooring
You have the flexibility to select the material and color for the interior finishing.
Walls and ceiling
- Wooden based wall panels Forestia (Norway, look like a painted wall) - a foil-coated wallpanel with tongue/groove and v-joint
- Wooden based wall panels Huntonit (Norway, look like wood cladding) - Probably the cleanest panel in the world, Patented brushpainted surface, Recommended by the Norwegian Asthma and Allergy Association, Approved with an Indoor Climate Award from the Danish Technological Institute, Pure product for a healty indoor climate, Durable and easy care - easy to clean, Easy to repaint with acrylic based paint
- Scandinavian pine cladding (120x19 or 146x19, vertical or horizontal) - painted with two layers of acrylic paint
Flooring
- Laminate (AC5, 8-10mm)
- Vinyl (class 33, 4-5mm)
- Parquet board (14 mm)
You have the flexibility to select the material and color for the interior finishing.
ELECTRICITY
All electrical installations and connections in the houses are carried out in the factory.
Electrical wiring made with NYM-J 3x1.5mm or 3x2.5mm cable and installed within a protective corrugated pipe and hidden in the construction to maximize design and appearance.
Spotlights with switches are included in all models according to the drawing. Optionally additional fasade lights, interior LED light, fasade LED light or fasade socket can be installed.
Sockets and switch buttons are consistently of the Schneider brand and are mounted in a way that they can accommodate all spaces.
The electrical center is equipped with automatic fuses and earth leakage circuit breakers.
Electrical wiring made with NYM-J 3x1.5mm or 3x2.5mm cable and installed within a protective corrugated pipe and hidden in the construction to maximize design and appearance.
Spotlights with switches are included in all models according to the drawing. Optionally additional fasade lights, interior LED light, fasade LED light or fasade socket can be installed.
Sockets and switch buttons are consistently of the Schneider brand and are mounted in a way that they can accommodate all spaces.
The electrical center is equipped with automatic fuses and earth leakage circuit breakers.
HEATING AND COOLING
Options of the heating:
- Electric convector heater (500W, 700W or 1000W)
- Air conditioner (heating/cooling)
- Electric underfloor heating
VENTILATION
The house ventilation system consists of supply air vents in the bed rooms and a forced ventilation fan in the bathroom that creates a constant negative pressure, drawing in fresh air through ventilation openings in the exterior walls.
WATER AND SEWERAGE
The plumbing and sewage systems is installed and connected to all the necessary fixtures in the bathroom, kitchen and technical room. The kitchen wall has standard connections for cold and hot water as well as drainage.
The sewage system features PVC pipes with a diameter of 50/110 mm, while the water supply is made with a polyethylene pipe with a diameter of 16-20 mm.
Hot water distribution is carried out via a hot water heater that holds 80L.
The sewage system features PVC pipes with a diameter of 50/110 mm, while the water supply is made with a polyethylene pipe with a diameter of 16-20 mm.
Hot water distribution is carried out via a hot water heater that holds 80L.
KITCHEN AND FURNITURE
KITCHEN
The kitchen with equipment is fully assembled in the factory. It has standard connections for cold and hot water, as well as drainage, and multiple electrical outlets.
The kitchen can be different for different models, there are some standard options:
Basic
The kitchen and equipment can be configured individually according to client needs.
FURNITURE
For models with Loft the ladder with the wardrobe is included by default. The ladder cabinet has laminated panels in white with drawers of different size.
Freestanding furniture is not included by default and available as an additional option.
The kitchen with equipment is fully assembled in the factory. It has standard connections for cold and hot water, as well as drainage, and multiple electrical outlets.
The kitchen can be different for different models, there are some standard options:
Basic
- Lower cabinets: 600-600-600mm
- Top: shelves
- Equipment: sink with washbasin, 2-burner hob
- Lower cabinets: 600-450-600-600mm (for models without loft) or 600-600-600mm (for models with loft)
- Top: shelves
- Equipment: sink with washbasin, 2-burner hob, built-in refrigerator, oven
The kitchen and equipment can be configured individually according to client needs.
FURNITURE
For models with Loft the ladder with the wardrobe is included by default. The ladder cabinet has laminated panels in white with drawers of different size.
Freestanding furniture is not included by default and available as an additional option.
BATHROOM
The plan of the bathroom depends of the model, but all bathrooms are complete in factory with fully finished interior, plumbing and furniture.
Finishing
Floor — Ceramic tiles 600x600
Walls — Vinyl wall panels (basic) or waterproof wall panels FIBO.
Equipment
Individual equipment and furniture is possible.
Finishing
Floor — Ceramic tiles 600x600
Walls — Vinyl wall panels (basic) or waterproof wall panels FIBO.
Equipment
- Washbasin 40 or 50 cm with mixer Grohe and cabinet under the sink
- Shower tray with shower system (thermostat) and overhead shower from Grohe
- Shower enclosures (optionally)
- Floor-mounted toilet (wallhung optionally)
- Water heater 80L
- Spotlights
- Exhaust fan
- Floor drain
- Heating floor (optionally)
- Electric towel dryer (optionally)
Individual equipment and furniture is possible.
ADDITIONAL OPTIONS
- Terrace
- Stairs
- Smoke detector
- Air conditioner enclosure
A popular build for you
We prepared a couple of examples with different equipment packages. You can always change the price adding or removing options. Contact Us for more info.
DEVELOPER
Climate shell version fully finished from the outside, without interior finishing, equipment, furniture, electricity and plumbing
- Single-module construction made of insulated wooden frame
- External finishing with roof and facade
- Door and windows
- The Loft construction without finishing (if has a loft)
BASIC
Turn-key modular house with basic materials and equipment
- Fully finished interior with basic materials
- Fully finished exterior with basic materials
- Windows white on inside and colored outside
- Fully-equipped bathroom with basic interior finishing, furniture and plumbing
- Electricity, plumbing and ventilation
- Kitchen with 2-burner hob and sink with washbasin
- Loft with a staircase-wardrobe (if has a loft)
MAX
Turn-key modular house featuring more options and upgraded finishes
- Interior and exterior with upgraded finishes
- Windows colored on inside and outside
- Bathroom with upgraded finishes and extra equipment
- Bigger kitchen with extra fridge and oven
- Air conditioner, underfloor heating
- Interior LED lightning, facade lights and socket
- Additional constructions like stairs and terraсe
- Foundation and groundworks
- Crane rental (for unloading)
- Building permit and individual statics calculation (if necessary)
- Connection to external utilities (electricity, water, etc.)
Contact Us to build your own configuration based on popular packages.
